STGP15H60DF Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3
- Description: IGBT 600V 30A 115W TO220
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGP15H60DF Specifications:
- MfrPart.: STGP15H60DF
- Mfr: STMicroelectronics
- Description: IGBT 600V 30A 115W TO220
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 30 A
- Current-CollectorPulsed(Icm): 60 A
- Vce(on)(Max)@VgeIc: 2V @ 15V, 15A
- Power-Max: 115 W
- SwitchingEnergy: 136µJ (on), 207µJ (off)
- InputType: Standard
- GateCharge: 81 nC
- Td(on/off)@25°C: 24.5ns/118ns
- TestCondition: 400V, 15A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 103 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3
- STGP15H60DF STMicroelectronics, IGBT 600V 30A 115W TO220, Discrete Semiconductor Products~Transistors - IGBTs - Single
STGP15H60DF, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
