STGP14NC60KD Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3
- Description: IGBT 600V 25A 80W TO220
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGP14NC60KD Specifications:
- MfrPart.: STGP14NC60KD
- Mfr: STMicroelectronics
- Description: IGBT 600V 25A 80W TO220
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: PowerMESH™
- PartStatus: Active
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 25 A
- Current-CollectorPulsed(Icm): 50 A
- Vce(on)(Max)@VgeIc: 2.5V @ 15V, 7A
- Power-Max: 80 W
- SwitchingEnergy: 82µJ (on), 155µJ (off)
- InputType: Standard
- GateCharge: 34.4 nC
- Td(on/off)@25°C: 22.5ns/116ns
- TestCondition: 390V, 7A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 37 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3
- STGP14NC60KD STMicroelectronics, IGBT 600V 25A 80W TO220, Discrete Semiconductor Products~Transistors - IGBTs - Single
