STGP10NC60K Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3
- Description: IGBT 600V 20A 60W TO220
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGP10NC60K Specifications:
- MfrPart.: STGP10NC60K
- Mfr: STMicroelectronics
- Description: IGBT 600V 20A 60W TO220
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: PowerMESH™
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 20 A
- Current-CollectorPulsed(Icm): 30 A
- Vce(on)(Max)@VgeIc: 2.5V @ 15V, 5A
- Power-Max: 60 W
- SwitchingEnergy: 55µJ (on), 85µJ (off)
- InputType: Standard
- GateCharge: 19 nC
- Td(on/off)@25°C: 17ns/72ns
- TestCondition: 390V, 5A, 10Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3
- STGP10NC60K STMicroelectronics, IGBT 600V 20A 60W TO220, Discrete Semiconductor Products~Transistors - IGBTs - Single
STGP10NC60K, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
