STGP10M65DF2 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3
- Description: IGBT 650V 10A TO-220AB
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGP10M65DF2 Specifications:
- MfrPart.: STGP10M65DF2
- Mfr: STMicroelectronics
- Description: IGBT 650V 10A TO-220AB
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 650 V
- Current-Collector(Ic)(Max): 20 A
- Current-CollectorPulsed(Icm): 40 A
- Vce(on)(Max)@VgeIc: 2V @ 15V, 10A
- Power-Max: 115 W
- SwitchingEnergy: 120µJ (on), 270µJ (off)
- InputType: Standard
- GateCharge: 28 nC
- Td(on/off)@25°C: 19ns/91ns
- TestCondition: 400V, 10A, 22Ohm, 15V
- ReverseRecoveryTime(trr): 96 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3
- STGP10M65DF2 STMicroelectronics, IGBT 650V 10A TO-220AB, Discrete Semiconductor Products~Transistors - IGBTs - Single
STGP10M65DF2, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
