STGFW20V60F Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-3P-3 Full Pack
- Description: IGBT 600V 40A 52W TO3PF
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGFW20V60F Specifications:
- MfrPart.: STGFW20V60F
- Mfr: STMicroelectronics
- Description: IGBT 600V 40A 52W TO3PF
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 40 A
- Current-CollectorPulsed(Icm): 80 A
- Vce(on)(Max)@VgeIc: 2.2V @ 15V, 20A
- Power-Max: 52 W
- SwitchingEnergy: 200µJ (on), 130µJ (off)
- InputType: Standard
- GateCharge: 116 nC
- Td(on/off)@25°C: 38ns/149ns
- TestCondition: 400V, 20A, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-3P-3 Full Pack
- STGFW20V60F STMicroelectronics, IGBT 600V 40A 52W TO3PF, Discrete Semiconductor Products~Transistors - IGBTs - Single
STGFW20V60F, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
