STGF3NC120HD Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3 Full Pack
- Description: IGBT 1200V 6A 25W TO220FP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGF3NC120HD Specifications:
- MfrPart.: STGF3NC120HD
- Mfr: STMicroelectronics
- Description: IGBT 1200V 6A 25W TO220FP
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: PowerMESH™
- PartStatus: Active
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 6 A
- Current-CollectorPulsed(Icm): 20 A
- Vce(on)(Max)@VgeIc: 2.8V @ 15V, 3A
- Power-Max: 25 W
- SwitchingEnergy: 236µJ (on), 290µJ (off)
- InputType: Standard
- GateCharge: 24 nC
- Td(on/off)@25°C: 15ns/118ns
- TestCondition: 800V, 3A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 51 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3 Full Pack
- STGF3NC120HD STMicroelectronics, IGBT 1200V 6A 25W TO220FP, Discrete Semiconductor Products~Transistors - IGBTs - Single
