STGF30NC60S Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3 Full Pack
- Description: IGBT 600V 22A 40W TO220FP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGF30NC60S Specifications:
- MfrPart.: STGF30NC60S
- Mfr: STMicroelectronics
- Description: IGBT 600V 22A 40W TO220FP
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: PowerMESH™
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 22 A
- Current-CollectorPulsed(Icm): 150 A
- Vce(on)(Max)@VgeIc: 1.9V @ 15V, 20A
- Power-Max: 40 W
- SwitchingEnergy: 300µJ (on), 1.28mJ (off)
- InputType: Standard
- GateCharge: 96 nC
- Td(on/off)@25°C: 21.5ns/180ns
- TestCondition: 480V, 20A, 10Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3 Full Pack
- STGF30NC60S STMicroelectronics, IGBT 600V 22A 40W TO220FP, Discrete Semiconductor Products~Transistors - IGBTs - Single
STGF30NC60S, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
