STGF30H60DF Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3 Full Pack
- Description: IGBT 600V 60A 37W TO220FP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGF30H60DF Specifications:
- MfrPart.: STGF30H60DF
- Mfr: STMicroelectronics
- Description: IGBT 600V 60A 37W TO220FP
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: -
- PartStatus: Obsolete
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 60 A
- Current-CollectorPulsed(Icm): 120 A
- Vce(on)(Max)@VgeIc: 2.4V @ 15V, 30A
- Power-Max: 37 W
- SwitchingEnergy: 350µJ (on), 400µJ (off)
- InputType: Standard
- GateCharge: 105 nC
- Td(on/off)@25°C: 50ns/160ns
- TestCondition: 400V, 30A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 110 ns
- OperatingTemperature: -40°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3 Full Pack
- STGF30H60DF STMicroelectronics, IGBT 600V 60A 37W TO220FP, Discrete Semiconductor Products~Transistors - IGBTs - Single
STGF30H60DF, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
