STGF12NB60KD ST IGBT 600V 14A 30W TO220FP
STGF12NB60KD Images
STGF12NB60KD Images
  • Manufacturer: STMicroelectronics(ST)
  • Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3 Full Pack
  • Description: IGBT 600V 14A 30W TO220FP
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
STGF12NB60KD Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
STGF12NB60KD Specifications:
  • MfrPart.: STGF12NB60KD
  • Mfr: STMicroelectronics
  • Description: IGBT 600V 14A 30W TO220FP
  • Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
  • Package: Tape & Reel (TR)
  • Series: PowerMESH™
  • PartStatus: Obsolete
  • IGBTType: -
  • Voltage-CollectorEmitterBreakdown(Max): 600 V
  • Current-Collector(Ic)(Max): 14 A
  • Current-CollectorPulsed(Icm): 60 A
  • Vce(on)(Max)@VgeIc: 2.8V @ 15V, 12A
  • Power-Max: 30 W
  • SwitchingEnergy: 152µJ (on), 258µJ (off)
  • InputType: Standard
  • GateCharge: 54 nC
  • Td(on/off)@25°C: 25ns/96ns
  • TestCondition: 480V, 12A, 10Ohm, 15V
  • ReverseRecoveryTime(trr): 37 ns
  • OperatingTemperature: -
  • MountingType: Through Hole
  • Package/Case: TO-220-3 Full Pack
  • STGF12NB60KD STMicroelectronics, IGBT 600V 14A 30W TO220FP, Discrete Semiconductor Products~Transistors - IGBTs - Single
STGF12NB60KD, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
