STGF10NC60SD Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-220-3 Full Pack
- Description: IGBT 600V 10A 25W TP220FP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGF10NC60SD Specifications:
- MfrPart.: STGF10NC60SD
- Mfr: STMicroelectronics
- Description: IGBT 600V 10A 25W TP220FP
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: PowerMESH™
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 10 A
- Current-CollectorPulsed(Icm): 25 A
- Vce(on)(Max)@VgeIc: 1.65V @ 15V, 5A
- Power-Max: 25 W
- SwitchingEnergy: 60µJ (on), 340µJ (off)
- InputType: Standard
- GateCharge: 18 nC
- Td(on/off)@25°C: 19ns/160ns
- TestCondition: 390V, 5A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 22 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3 Full Pack
- STGF10NC60SD STMicroelectronics, IGBT 600V 10A 25W TP220FP, Discrete Semiconductor Products~Transistors - IGBTs - Single
