STGD7NB120S-1 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-251-3 Short Leads, IPak, TO-251AA
- Description: IGBT 1200V 10A 55W IPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGD7NB120S-1 Specifications:
- MfrPart.: STGD7NB120S-1
- Mfr: STMicroelectronics
- Description: IGBT 1200V 10A 55W IPAK
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: PowerMESH™
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 1200 V
- Current-Collector(Ic)(Max): 10 A
- Current-CollectorPulsed(Icm): 20 A
- Vce(on)(Max)@VgeIc: 2.1V @ 15V, 7A
- Power-Max: 55 W
- SwitchingEnergy: 15mJ (off)
- InputType: Standard
- GateCharge: 29 nC
- Td(on/off)@25°C: 570ns/-
- TestCondition: 960V, 7A, 1kOhm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-251-3 Short Leads, IPak, TO-251AA
- STGD7NB120S-1 STMicroelectronics, IGBT 1200V 10A 55W IPAK, Discrete Semiconductor Products~Transistors - IGBTs - Single
