STGD3NB60SD-1 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Description: IGBT 600V 6A 48W DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGD3NB60SD-1 Specifications:
- MfrPart.: STGD3NB60SD-1
- Mfr: STMicroelectronics
- Description: IGBT 600V 6A 48W DPAK
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: PowerMESH™
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 6 A
- Current-CollectorPulsed(Icm): 25 A
- Vce(on)(Max)@VgeIc: 1.5V @ 15V, 3A
- Power-Max: 48 W
- SwitchingEnergy: 1.1mJ (on), 1.15mJ (off)
- InputType: Standard
- GateCharge: 18 nC
- Td(on/off)@25°C: 125µs/3.4µs
- TestCondition: 480V, 3A, 1kOhm, 15V
- ReverseRecoveryTime(trr): 1.7 µs
- OperatingTemperature: 175°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- STGD3NB60SD-1 STMicroelectronics, IGBT 600V 6A 48W DPAK, Discrete Semiconductor Products~Transistors - IGBTs - Single
