STGD20N45LZAG Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Description: POWER TRANSISTORS
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGD20N45LZAG Specifications:
- MfrPart.: STGD20N45LZAG
- Mfr: STMicroelectronics
- Description: POWER TRANSISTORS
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: Automotive, AEC-Q101
- PartStatus: Active
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 450 V
- Current-Collector(Ic)(Max): 25 A
- Current-CollectorPulsed(Icm): 50 A
- Vce(on)(Max)@VgeIc: 1.25V @ 4V, 6A
- Power-Max: 125 W
- SwitchingEnergy: -
- InputType: Logic
- GateCharge: 26 nC
- Td(on/off)@25°C: 1.1µs/4.6µs
- TestCondition: 300V, 10A, 1kOhm, 5V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- STGD20N45LZAG STMicroelectronics, POWER TRANSISTORS, Discrete Semiconductor Products~Transistors - IGBTs - Single
STGD20N45LZAG, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
