STGD18N40LZ-1 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-251-3 Short Leads, IPak, TO-251AA
- Description: IGBT 420V 25A 125W IPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGD18N40LZ-1 Specifications:
- MfrPart.: STGD18N40LZ-1
- Mfr: STMicroelectronics
- Description: IGBT 420V 25A 125W IPAK
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: PowerMESH™
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 420 V
- Current-Collector(Ic)(Max): 25 A
- Current-CollectorPulsed(Icm): 40 A
- Vce(on)(Max)@VgeIc: 1.7V @ 4.5V, 10A
- Power-Max: 125 W
- SwitchingEnergy: -
- InputType: Logic
- GateCharge: 29 nC
- Td(on/off)@25°C: 650ns/13.5µs
- TestCondition: 300V, 10A, 5V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-251-3 Short Leads, IPak, TO-251AA
- STGD18N40LZ-1 STMicroelectronics, IGBT 420V 25A 125W IPAK, Discrete Semiconductor Products~Transistors - IGBTs - Single
