STGD10NC60SDT4 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- Description: IGBT 600V 18A 60W DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGD10NC60SDT4 Specifications:
- MfrPart.: STGD10NC60SDT4
- Mfr: STMicroelectronics
- Description: IGBT 600V 18A 60W DPAK
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: PowerMESH™
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 18 A
- Current-CollectorPulsed(Icm): 25 A
- Vce(on)(Max)@VgeIc: 1.65V @ 15V, 5A
- Power-Max: 60 W
- SwitchingEnergy: 60µJ (on), 340µJ (off)
- InputType: Standard
- GateCharge: 18 nC
- Td(on/off)@25°C: 19ns/160ns
- TestCondition: 390V, 5A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 22 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-252-3, DPak (2 Leads + Tab), SC-63
- STGD10NC60SDT4 STMicroelectronics, IGBT 600V 18A 60W DPAK, Discrete Semiconductor Products~Transistors - IGBTs - Single
STGD10NC60SDT4, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
