STGBL6NC60DIT4 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Description: IGBT 600V 14A 56W D2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGBL6NC60DIT4 Specifications:
- MfrPart.: STGBL6NC60DIT4
- Mfr: STMicroelectronics
- Description: IGBT 600V 14A 56W D2PAK
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: PowerMESH™
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 14 A
- Current-CollectorPulsed(Icm): 18 A
- Vce(on)(Max)@VgeIc: 2.9V @ 15V, 3A
- Power-Max: 56 W
- SwitchingEnergy: 32µJ (on), 24µJ (off)
- InputType: Standard
- GateCharge: 12 nC
- Td(on/off)@25°C: 6.7ns/46ns
- TestCondition: 390V, 3A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 23 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- STGBL6NC60DIT4 STMicroelectronics, IGBT 600V 14A 56W D2PAK, Discrete Semiconductor Products~Transistors - IGBTs - Single
