STGB6NC60HD-1 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-262-3 Long Leads, I²Pak, TO-262AA
- Description: IGBT 600V 15A 56W I2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGB6NC60HD-1 Specifications:
- MfrPart.: STGB6NC60HD-1
- Mfr: STMicroelectronics
- Description: IGBT 600V 15A 56W I2PAK
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tube
- Series: PowerMESH™
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 15 A
- Current-CollectorPulsed(Icm): 21 A
- Vce(on)(Max)@VgeIc: 2.5V @ 15V, 3A
- Power-Max: 56 W
- SwitchingEnergy: 20µJ (on), 68µJ (off)
- InputType: Standard
- GateCharge: 13.6 nC
- Td(on/off)@25°C: 12ns/76ns
- TestCondition: 390V, 3A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 21 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-262-3 Long Leads, I²Pak, TO-262AA
- STGB6NC60HD-1 STMicroelectronics, IGBT 600V 15A 56W I2PAK, Discrete Semiconductor Products~Transistors - IGBTs - Single
