STGB5H60DF Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Description: TRENCH GATE FIELD-STOP IGBT, H S
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGB5H60DF Specifications:
- MfrPart.: STGB5H60DF
- Mfr: STMicroelectronics
- Description: TRENCH GATE FIELD-STOP IGBT, H S
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tape & Reel (TR),Cut Tape (CT),Bulk
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 10 A
- Current-CollectorPulsed(Icm): 20 A
- Vce(on)(Max)@VgeIc: 1.95V @ 15V, 5A
- Power-Max: 88 W
- SwitchingEnergy: 56µJ (on), 78.5µJ (off)
- InputType: Standard
- GateCharge: 43 nC
- Td(on/off)@25°C: 30ns/140ns
- TestCondition: 400V, 5A, 47Ohm, 15V
- ReverseRecoveryTime(trr): 134.5 ns
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- STGB5H60DF STMicroelectronics, TRENCH GATE FIELD-STOP IGBT, H S, Discrete Semiconductor Products~Transistors - IGBTs - Single
