STGB30H60DLFB Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Description: TRENCH GATE FIELD-STOP IGBT, HB
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGB30H60DLFB Specifications:
- MfrPart.: STGB30H60DLFB
- Mfr: STMicroelectronics
- Description: TRENCH GATE FIELD-STOP IGBT, HB
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- IGBTType: Trench Field Stop
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 60 A
- Current-CollectorPulsed(Icm): 120 A
- Vce(on)(Max)@VgeIc: 2V @ 15V, 30A
- Power-Max: 260 W
- SwitchingEnergy: 393µJ (off)
- InputType: Standard
- GateCharge: 149 nC
- Td(on/off)@25°C: -/146ns
- TestCondition: 400V, 30A, 10Ohm, 15V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- STGB30H60DLFB STMicroelectronics, TRENCH GATE FIELD-STOP IGBT, HB, Discrete Semiconductor Products~Transistors - IGBTs - Single
STGB30H60DLFB, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
