STGB20NB41LZT4 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Description: IGBT 442V 40A 200W D2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGB20NB41LZT4 Specifications:
- MfrPart.: STGB20NB41LZT4
- Mfr: STMicroelectronics
- Description: IGBT 442V 40A 200W D2PAK
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: PowerMESH™
- PartStatus: Active
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 442 V
- Current-Collector(Ic)(Max): 40 A
- Current-CollectorPulsed(Icm): 80 A
- Vce(on)(Max)@VgeIc: 2V @ 4.5V, 20A
- Power-Max: 200 W
- SwitchingEnergy: 5mJ (on), 12.9mJ (off)
- InputType: Standard
- GateCharge: 46 nC
- Td(on/off)@25°C: 1µs/12.1µs
- TestCondition: 320V, 20A, 1kOhm, 5V
- ReverseRecoveryTime(trr): -
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- STGB20NB41LZT4 STMicroelectronics, IGBT 442V 40A 200W D2PAK, Discrete Semiconductor Products~Transistors - IGBTs - Single
