STGB12NB60KDT4 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Description: IGBT 600V 30A 125W D2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGB12NB60KDT4 Specifications:
- MfrPart.: STGB12NB60KDT4
- Mfr: STMicroelectronics
- Description: IGBT 600V 30A 125W D2PAK
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: PowerMESH™
- PartStatus: Obsolete
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 30 A
- Current-CollectorPulsed(Icm): 60 A
- Vce(on)(Max)@VgeIc: 2.8V @ 15V, 12A
- Power-Max: 125 W
- SwitchingEnergy: 258µJ (off)
- InputType: Standard
- GateCharge: 54 nC
- Td(on/off)@25°C: 25ns/96ns
- TestCondition: 480V, 12A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 80 ns
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- STGB12NB60KDT4 STMicroelectronics, IGBT 600V 30A 125W D2PAK, Discrete Semiconductor Products~Transistors - IGBTs - Single
