STGB10NC60HDT4 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - IGBTs - Single Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Description: IGBT 600V 20A 65W D2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGB10NC60HDT4 Specifications:
- MfrPart.: STGB10NC60HDT4
- Mfr: STMicroelectronics
- Description: IGBT 600V 20A 65W D2PAK
- Product Category: Discrete Semiconductor Products~Transistors - IGBTs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: PowerMESH™
- PartStatus: Active
- IGBTType: -
- Voltage-CollectorEmitterBreakdown(Max): 600 V
- Current-Collector(Ic)(Max): 20 A
- Current-CollectorPulsed(Icm): 30 A
- Vce(on)(Max)@VgeIc: 2.5V @ 15V, 5A
- Power-Max: 65 W
- SwitchingEnergy: 31.8µJ (on), 95µJ (off)
- InputType: Standard
- GateCharge: 19.2 nC
- Td(on/off)@25°C: 14.2ns/72ns
- TestCondition: 390V, 5A, 10Ohm, 15V
- ReverseRecoveryTime(trr): 22 ns
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- Package/Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- STGB10NC60HDT4 STMicroelectronics, IGBT 600V 20A 65W D2PAK, Discrete Semiconductor Products~Transistors - IGBTs - Single
STGB10NC60HDT4, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
