STGAP1AS Images
- Manufacturer: STMicroelectronics(ST)
- Category: Isolators~Isolators - Gate Drivers Package/Case: 24-SOIC (0.295, 7.50mm Width)
- Description: DGTL ISO 2.5KV 1CH GATE DVR 24SO
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STGAP1AS Specifications:
- MfrPart.: STGAP1AS
- Mfr: STMicroelectronics
- Description: DGTL ISO 2.5KV 1CH GATE DVR 24SO
- Product Category: Isolators~Isolators - Gate Drivers
- Package: Tube
- Series: Automotive, AEC-Q100
- PartStatus: Obsolete
- Technology: Magnetic Coupling
- NumberofChannels: 1
- Voltage-Isolation: 2500Vrms
- CommonModeTransientImmunity(Min): -
- PropagationDelaytpLH/tpHL(Max): 130ns, 130ns
- PulseWidthDistortion(Max): 10ns
- Rise/FallTime(Typ): 25ns, 25ns (Max)
- Current-OutputHighLow: 2.5A, 2.5A
- Current-PeakOutput: -
- Voltage-Forward(Vf)(Typ): -
- Current-DCForward(If)(Max): -
- Voltage-OutputSupply: 4.5V ~ 36V
- OperatingTemperature: -40°C ~ 125°C
- MountingType: Surface Mount
- Package/Case: 24-SOIC (0.295, 7.50mm Width)
- STGAP1AS STMicroelectronics, DGTL ISO 2.5KV 1CH GATE DVR 24SO, Isolators~Isolators - Gate Drivers
STGAP1AS, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
