STG5683QTR Images
- Manufacturer: STMicroelectronics(ST)
- Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-UFQFN
- Description: IC SWITCH DUAL SPDT 16QFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STG5683QTR Specifications:
- MfrPart.: STG5683QTR
- Mfr: STMicroelectronics
- Description: IC SWITCH DUAL SPDT 16QFN
- Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Obsolete
- SwitchCircuit: SPDT
- Multiplexer/DemultiplexerCircuit: 2:1
- NumberofCircuits: 2
- On-StateResistance(Max): 550mOhm
- Channel-to-ChannelMatching(ΔRon): 15mOhm
- Voltage-SupplySingle(V+): 1.65V ~ 4.5V
- Voltage-SupplyDual(V±): -
- SwitchTime(TonToff)(Max): 80ns, 50ns
- -3dbBandwidth: 33MHz
- ChargeInjection: 46pC
- ChannelCapacitance(CS(off)CD(off)): 6pF
- Current-Leakage(IS(off))(Max): -
- Crosstalk: -60dB @ 100kHz
- OperatingTemperature: -40°C ~ 85°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-UFQFN
- STG5683QTR STMicroelectronics, IC SWITCH DUAL SPDT 16QFN, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
STG5683QTR, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
