STG3680QTR ST IC SWITCH DUAL 2X1 16QFN
STG3680QTR Images
STG3680QTR Images
  • Manufacturer: STMicroelectronics(ST)
  • Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers Package/Case: 16-VFQFN Exposed Pad
  • Description: IC SWITCH DUAL 2X1 16QFN
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
STG3680QTR Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
STG3680QTR Specifications:
  • MfrPart.: STG3680QTR
  • Mfr: STMicroelectronics
  • Description: IC SWITCH DUAL 2X1 16QFN
  • Product Category: Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
  • Package: Tape & Reel (TR),Cut Tape (CT)
  • Series: -
  • PartStatus: Obsolete
  • SwitchCircuit: SPDT
  • Multiplexer/DemultiplexerCircuit: 2:1
  • NumberofCircuits: 2
  • On-StateResistance(Max): 800mOhm
  • Channel-to-ChannelMatching(ΔRon): 60mOhm
  • Voltage-SupplySingle(V+): 1.65V ~ 4.3V
  • Voltage-SupplyDual(V±): -
  • SwitchTime(TonToff)(Max): 50ns, 30ns
  • -3dbBandwidth: 50MHz
  • ChargeInjection: 35pC
  • ChannelCapacitance(CS(off)CD(off)): 5pF
  • Current-Leakage(IS(off))(Max): 10nA
  • Crosstalk: -54dB @ 100kHz
  • OperatingTemperature: -55°C ~ 125°C (TA)
  • MountingType: Surface Mount
  • Package/Case: 16-VFQFN Exposed Pad
  • STG3680QTR STMicroelectronics, IC SWITCH DUAL 2X1 16QFN, Integrated Circuits (ICs)~Interface - Analog Switches, Multiplexers, Demultiplexers
STG3680QTR, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
