STF25NM50N Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-220FP
- Description: MOSFET N-CH 500V 22A TO220FP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STF25NM50N Specifications:
- MfrPart.: STF25NM50N
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 500V 22A TO220FP
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: MDmesh™ II
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 500 V
- Current-ContinuousDrain(Id)@25°C: 22A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 140mOhm @ 11A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 84 nC @ 10 V
- Vgs(Max): ±25V
- InputCapacitance(Ciss)(Max)@Vds: 2565 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 40W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: TO-220FP
- STF25NM50N STMicroelectronics, MOSFET N-CH 500V 22A TO220FP, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STF25NM50N, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
