STDRIVE601 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers Package/Case: 28-SOIC (0.295, 7.50mm Width)
- Description: TRIPLE HALF-BRIDGE HIGH-VOLTAGE
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STDRIVE601 Specifications:
- MfrPart.: STDRIVE601
- Mfr: STMicroelectronics
- Description: TRIPLE HALF-BRIDGE HIGH-VOLTAGE
- Product Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
- Package: Tray
- Series: -
- PartStatus: Active
- OutputConfiguration: Half Bridge (3)
- Applications: DC Motors, General Purpose
- Interface: Analog, Logic
- LoadType: Capacitive and Resistive
- Technology: Power MOSFET, IGBT
- RdsOn(Typ): 35Ohm
- Current-Output/Channel: -
- Current-PeakOutput: 350mA
- Voltage-Supply: 9V ~ 20V
- Voltage-Load: 580V
- OperatingTemperature: -40°C ~ 125°C (TJ)
- Features: Bootstrap Circuit
- FaultProtection: Over Current, Over Temperature, UVLO
- MountingType: Surface Mount
- Package/Case: 28-SOIC (0.295, 7.50mm Width)
- STDRIVE601 STMicroelectronics, TRIPLE HALF-BRIDGE HIGH-VOLTAGE, Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
STDRIVE601, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
