STD9NM40N Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: DPAK
- Description: MOSFET N-CH 400V 5.6A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STD9NM40N Specifications:
- MfrPart.: STD9NM40N
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 400V 5.6A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: MDmesh™ II
- PartStatus: Not For New Designs
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 400 V
- Current-ContinuousDrain(Id)@25°C: 5.6A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 790mOhm @ 2.5A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 14 nC @ 10 V
- Vgs(Max): ±25V
- InputCapacitance(Ciss)(Max)@Vds: 365 pF @ 50 V
- FETFeature: -
- PowerDissipation(Max): 60W (Tc)
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: DPAK
- STD9NM40N STMicroelectronics, MOSFET N-CH 400V 5.6A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STD9NM40N, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
