STD90NS3LLH7 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: DPAK
- Description: MOSFET N-CHANNEL 30V 80A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STD90NS3LLH7 Specifications:
- MfrPart.: STD90NS3LLH7
- Mfr: STMicroelectronics
- Description: MOSFET N-CHANNEL 30V 80A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: STripFET™ H7
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 80A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 3.4mOhm @ 40A, 10V
- Vgs(th)(Max)@Id: 1.2V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 13.7 nC @ 4.5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 2110 pF @ 25 V
- FETFeature: Schottky Diode (Body)
- PowerDissipation(Max): 57W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: DPAK
- STD90NS3LLH7 STMicroelectronics, MOSFET N-CHANNEL 30V 80A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STD90NS3LLH7, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
