STD7NM80-1 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: I-PAK
- Description: MOSFET N-CH 800V 6.5A IPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STD7NM80-1 Specifications:
- MfrPart.: STD7NM80-1
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 800V 6.5A IPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: MDmesh™
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 800 V
- Current-ContinuousDrain(Id)@25°C: 6.5A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 1.05Ohm @ 3.25A, 10V
- Vgs(th)(Max)@Id: 5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 18 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 620 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 90W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: I-PAK
- STD7NM80-1 STMicroelectronics, MOSFET N-CH 800V 6.5A IPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STD7NM80-1, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
