STD65NF06 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: DPAK
- Description: MOSFET N-CH 60V 60A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STD65NF06 Specifications:
- MfrPart.: STD65NF06
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 60V 60A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: STripFET™ II
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 60 V
- Current-ContinuousDrain(Id)@25°C: 60A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 14mOhm @ 30A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 75 nC @ 10 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 1700 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 110W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: DPAK
- STD65NF06 STMicroelectronics, MOSFET N-CH 60V 60A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STD65NF06, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
