STD65N3LLH5 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: DPAK
- Description: MOSFET N CH 30V 65A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STD65N3LLH5 Specifications:
- MfrPart.: STD65N3LLH5
- Mfr: STMicroelectronics
- Description: MOSFET N CH 30V 65A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: STripFET™ V
- PartStatus: Obsolete
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 65A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 6.9mOhm @ 32.5A, 10V
- Vgs(th)(Max)@Id: 3V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 8 nC @ 4.5 V
- Vgs(Max): ±22V
- InputCapacitance(Ciss)(Max)@Vds: 1290 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 50W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: DPAK
- STD65N3LLH5 STMicroelectronics, MOSFET N CH 30V 65A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
