STD5NM50AG Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: TO-252 (D-Pak)
- Description: MOSFET N-CH 500V 7.5A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STD5NM50AG Specifications:
- MfrPart.: STD5NM50AG
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 500V 7.5A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR)
- Series: MDmesh™
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 500 V
- Current-ContinuousDrain(Id)@25°C: 7.5A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 800mOhm @ 2.5A, 10V
- Vgs(th)(Max)@Id: 5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 13 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 415 pF @ 100 V
- FETFeature: -
- PowerDissipation(Max): 100W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: TO-252 (D-Pak)
- STD5NM50AG STMicroelectronics, MOSFET N-CH 500V 7.5A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STD5NM50AG, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
