STD5N52U Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: DPAK
- Description: MOSFET N-CH 525V 4.4A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STD5N52U Specifications:
- MfrPart.: STD5N52U
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 525V 4.4A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: UltraFASTmesh™
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 525 V
- Current-ContinuousDrain(Id)@25°C: 4.4A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 1.5Ohm @ 2.2A, 10V
- Vgs(th)(Max)@Id: 4.5V @ 50µA
- GateCharge(Qg)(Max)@Vgs: 16.9 nC @ 10 V
- Vgs(Max): ±30V
- InputCapacitance(Ciss)(Max)@Vds: 529 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 70W (Tc)
- OperatingTemperature: -55°C ~ 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: DPAK
- STD5N52U STMicroelectronics, MOSFET N-CH 525V 4.4A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
