STD52P3LLH6 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: DPAK
- Description: MOSFET P-CH 30V 52A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STD52P3LLH6 Specifications:
- MfrPart.: STD52P3LLH6
- Mfr: STMicroelectronics
- Description: MOSFET P-CH 30V 52A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: STripFET™ H6
- PartStatus: Active
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 52A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 4.5V, 10V
- RdsOn(Max)@IdVgs: 12mOhm @ 26A, 10V
- Vgs(th)(Max)@Id: 2.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 33 nC @ 4.5 V
- Vgs(Max): ±20V
- InputCapacitance(Ciss)(Max)@Vds: 3350 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 70W (Tc)
- OperatingTemperature: 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: DPAK
- STD52P3LLH6 STMicroelectronics, MOSFET P-CH 30V 52A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
