STD30PF03L-1 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: I-PAK
- Description: MOSFET P-CH 30V 24A IPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STD30PF03L-1 Specifications:
- MfrPart.: STD30PF03L-1
- Mfr: STMicroelectronics
- Description: MOSFET P-CH 30V 24A IPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: STripFET™ II
- PartStatus: Obsolete
- FETType: P-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 24A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 5V, 10V
- RdsOn(Max)@IdVgs: 28mOhm @ 12A, 10V
- Vgs(th)(Max)@Id: 1V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 28 nC @ 5 V
- Vgs(Max): ±16V
- InputCapacitance(Ciss)(Max)@Vds: 1670 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 70W (Tc)
- OperatingTemperature: 175°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: I-PAK
- STD30PF03L-1 STMicroelectronics, MOSFET P-CH 30V 24A IPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
