STD14NM50NAG Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: DPAK
- Description: MOSFET N-CH 500V 12A DPAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STD14NM50NAG Specifications:
- MfrPart.: STD14NM50NAG
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 500V 12A DPAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: Automotive, AEC-Q101, MDmesh™ II
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 500 V
- Current-ContinuousDrain(Id)@25°C: 12A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 320mOhm @ 6A, 10V
- Vgs(th)(Max)@Id: 4V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 27 nC @ 10 V
- Vgs(Max): ±25V
- InputCapacitance(Ciss)(Max)@Vds: 816 pF @ 50 V
- FETFeature: -
- PowerDissipation(Max): 90W
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: DPAK
- STD14NM50NAG STMicroelectronics, MOSFET N-CH 500V 12A DPAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STD14NM50NAG, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
