STB80N20M5 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D2PAK
- Description: MOSFET N-CH 200V 61A D2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STB80N20M5 Specifications:
- MfrPart.: STB80N20M5
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 200V 61A D2PAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: MDmesh™ V
- PartStatus: Active
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 200 V
- Current-ContinuousDrain(Id)@25°C: 61A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 10V
- RdsOn(Max)@IdVgs: 23mOhm @ 30.5A, 10V
- Vgs(th)(Max)@Id: 5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 104 nC @ 10 V
- Vgs(Max): ±25V
- InputCapacitance(Ciss)(Max)@Vds: 4329 pF @ 50 V
- FETFeature: -
- PowerDissipation(Max): 190W (Tc)
- OperatingTemperature: 150°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D2PAK
- STB80N20M5 STMicroelectronics, MOSFET N-CH 200V 61A D2PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
