STB70NF03LT4 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D2PAK
- Description: MOSFET N-CH 30V 70A D2PAK
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
STB70NF03LT4 Specifications:
- MfrPart.: STB70NF03LT4
- Mfr: STMicroelectronics
- Description: MOSFET N-CH 30V 70A D2PAK
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: STripFET™ II
- PartStatus: Not For New Designs
- FETType: N-Channel
- Technology: MOSFET (Metal Oxide)
- DraintoSourceVoltage(Vdss): 30 V
- Current-ContinuousDrain(Id)@25°C: 70A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 5V, 10V
- RdsOn(Max)@IdVgs: 9.5mOhm @ 35A, 10V
- Vgs(th)(Max)@Id: 1V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 30 nC @ 5 V
- Vgs(Max): ±18V
- InputCapacitance(Ciss)(Max)@Vds: 1440 pF @ 25 V
- FETFeature: -
- PowerDissipation(Max): 100W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: D2PAK
- STB70NF03LT4 STMicroelectronics, MOSFET N-CH 30V 70A D2PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
