STB11NM60T4 ST MOSFET N-CH 650V 11A D2PAK
STB11NM60T4 Images
STB11NM60T4 Images
  • Manufacturer: STMicroelectronics(ST)
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: D2PAK
  • Description: MOSFET N-CH 650V 11A D2PAK
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
STB11NM60T4 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
STB11NM60T4 Specifications:
  • MfrPart.: STB11NM60T4
  • Mfr: STMicroelectronics
  • Description: MOSFET N-CH 650V 11A D2PAK
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Tape & Reel (TR),Cut Tape (CT)
  • Series: MDmesh™
  • PartStatus: Not For New Designs
  • FETType: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • DraintoSourceVoltage(Vdss): 650 V
  • Current-ContinuousDrain(Id)@25°C: 11A (Tc)
  • DriveVoltage(MaxRdsOnMinRdsOn): 10V
  • RdsOn(Max)@IdVgs: 450mOhm @ 5.5A, 10V
  • Vgs(th)(Max)@Id: 5V @ 250µA
  • GateCharge(Qg)(Max)@Vgs: 30 nC @ 10 V
  • Vgs(Max): ±30V
  • InputCapacitance(Ciss)(Max)@Vds: 1000 pF @ 25 V
  • FETFeature: -
  • PowerDissipation(Max): 160W (Tc)
  • OperatingTemperature: -65°C ~ 150°C (TJ)
  • MountingType: Surface Mount
  • SupplierDevicePackage: D2PAK
  • STB11NM60T4 STMicroelectronics, MOSFET N-CH 650V 11A D2PAK, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
STB11NM60T4, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
