SG2525AP Images
- Manufacturer: STMicroelectronics(ST)
- Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers Package/Case: 16-SOIC (0.154, 3.90mm Width)
- Description: IC REG CTRLR BCK/PSH-PULL 16SOIC
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SG2525AP Specifications:
- MfrPart.: SG2525AP
- Mfr: STMicroelectronics
- Description: IC REG CTRLR BCK/PSH-PULL 16SOIC
- Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers
- Package: Tube
- Series: -
- PartStatus: Active
- OutputType: Transistor Driver
- Function: Step-Down, Step-Up/Step-Down
- OutputConfiguration: Positive
- Topology: Buck, Push-Pull
- NumberofOutputs: 2
- OutputPhases: 1
- Voltage-Supply(Vcc/Vdd): 8V ~ 35V
- Frequency-Switching: 100Hz ~ 400kHz
- DutyCycle(Max): 49%
- SynchronousRectifier: Yes
- ClockSync: Yes
- SerialInterfaces: -
- ControlFeatures: Enable, Soft Start
- OperatingTemperature: -25°C ~ 85°C (TA)
- MountingType: Surface Mount
- Package/Case: 16-SOIC (0.154, 3.90mm Width)
- SG2525AP STMicroelectronics, IC REG CTRLR BCK/PSH-PULL 16SOIC, Integrated Circuits (ICs)~PMIC - Voltage Regulators - DC DC Switching Controllers
SG2525AP, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
