SCTH70N120G2V-7 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: H2PAK-7
- Description: SILICON CARBIDE POWER MOSFET 120
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SCTH70N120G2V-7 Specifications:
- MfrPart.: SCTH70N120G2V-7
- Mfr: STMicroelectronics
- Description: SILICON CARBIDE POWER MOSFET 120
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: SiC (Silicon Carbide Junction Transistor)
- DraintoSourceVoltage(Vdss): 1200 V
- Current-ContinuousDrain(Id)@25°C: 90A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 18V
- RdsOn(Max)@IdVgs: 30mOhm @ 50A, 18V
- Vgs(th)(Max)@Id: 4.9V @ 1mA
- GateCharge(Qg)(Max)@Vgs: 150 nC @ 18 V
- Vgs(Max): +22V, -10V
- InputCapacitance(Ciss)(Max)@Vds: 3540 pF @ 800 V
- FETFeature: -
- PowerDissipation(Max): 469W (Tc)
- OperatingTemperature: -55°C ~ 175°C (TJ)
- MountingType: Surface Mount
- SupplierDevicePackage: H2PAK-7
- SCTH70N120G2V-7 STMicroelectronics, SILICON CARBIDE POWER MOSFET 120, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
