SCT30N120D2 ST SICFET N-CH 1200V 40A HIP247
SCT30N120D2 Images
SCT30N120D2 Images
  • Manufacturer: STMicroelectronics(ST)
  • Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: HiP247™
  • Description: SICFET N-CH 1200V 40A HIP247
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
SCT30N120D2 Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
SCT30N120D2 Specifications:
  • MfrPart.: SCT30N120D2
  • Mfr: STMicroelectronics
  • Description: SICFET N-CH 1200V 40A HIP247
  • Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
  • Package: Tray
  • Series: -
  • PartStatus: Active
  • FETType: N-Channel
  • Technology: SiCFET (Silicon Carbide)
  • DraintoSourceVoltage(Vdss): 1200 V
  • Current-ContinuousDrain(Id)@25°C: 40A (Tc)
  • DriveVoltage(MaxRdsOnMinRdsOn): 20V
  • RdsOn(Max)@IdVgs: 100mOhm @ 20A, 20V
  • Vgs(th)(Max)@Id: 3.5V @ 1mA
  • GateCharge(Qg)(Max)@Vgs: 105 nC @ 20 V
  • Vgs(Max): +25V, -10V
  • InputCapacitance(Ciss)(Max)@Vds: 1700 pF @ 400 V
  • FETFeature: -
  • PowerDissipation(Max): 270W (Tc)
  • OperatingTemperature: -55°C ~ 200°C (TJ)
  • MountingType: Through Hole
  • SupplierDevicePackage: HiP247™
  • SCT30N120D2 STMicroelectronics, SICFET N-CH 1200V 40A HIP247, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
SCT30N120D2, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
