SCT10N120 Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single SupplierDevicePackage: HiP247™
- Description: SICFET N-CH 1200V 12A HIP247
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
SCT10N120 Specifications:
- MfrPart.: SCT10N120
- Mfr: STMicroelectronics
- Description: SICFET N-CH 1200V 12A HIP247
- Product Category: Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
- Package: Tube
- Series: -
- PartStatus: Active
- FETType: N-Channel
- Technology: SiCFET (Silicon Carbide)
- DraintoSourceVoltage(Vdss): 1200 V
- Current-ContinuousDrain(Id)@25°C: 12A (Tc)
- DriveVoltage(MaxRdsOnMinRdsOn): 20V
- RdsOn(Max)@IdVgs: 690mOhm @ 6A, 20V
- Vgs(th)(Max)@Id: 3.5V @ 250µA
- GateCharge(Qg)(Max)@Vgs: 22 nC @ 20 V
- Vgs(Max): +25V, -10V
- InputCapacitance(Ciss)(Max)@Vds: 290 pF @ 400 V
- FETFeature: -
- PowerDissipation(Max): 150W (Tc)
- OperatingTemperature: -55°C ~ 200°C (TJ)
- MountingType: Through Hole
- SupplierDevicePackage: HiP247™
- SCT10N120 STMicroelectronics, SICFET N-CH 1200V 12A HIP247, Discrete Semiconductor Products~Transistors - FETs, MOSFETs - Single
SCT10N120, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
