MD1803DFP Images
- Manufacturer: STMicroelectronics(ST)
- Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single Package/Case: TO-220-3 Full Pack
- Description: TRANS NPN 700V 10A TO-220FP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
MD1803DFP Specifications:
- MfrPart.: MD1803DFP
- Mfr: STMicroelectronics
- Description: TRANS NPN 700V 10A TO-220FP
- Product Category: Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
- Package: Tube
- Series: -
- PartStatus: Active
- TransistorType: NPN
- Current-Collector(Ic)(Max): 10 A
- Voltage-CollectorEmitterBreakdown(Max): 700 V
- VceSaturation(Max)@IbIc: 2V @ 1.25A, 5A
- Current-CollectorCutoff(Max): 200µA
- DCCurrentGain(hFE)(Min)@IcVce: 5.5 @ 5A, 5V
- Power-Max: 40 W
- Frequency-Transition: -
- OperatingTemperature: 150°C (TJ)
- MountingType: Through Hole
- Package/Case: TO-220-3 Full Pack
- MD1803DFP STMicroelectronics, TRANS NPN 700V 10A TO-220FP, Discrete Semiconductor Products~Transistors - Bipolar (BJT) - Single
MD1803DFP, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
