M74HC02TTR Images
- Manufacturer: STMicroelectronics(ST)
- Category: Integrated Circuits (ICs)~Logic - Gates and Inverters SupplierDevicePackage: 14-TSSOP
- Description: IC GATE NOR 4CH 2-INP 14TSSOP
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
M74HC02TTR Specifications:
- MfrPart.: M74HC02TTR
- Mfr: STMicroelectronics
- Description: IC GATE NOR 4CH 2-INP 14TSSOP
- Product Category: Integrated Circuits (ICs)~Logic - Gates and Inverters
- Package: Tape & Reel (TR)
- Series: 74HC
- PartStatus: Obsolete
- LogicType: NOR Gate
- NumberofCircuits: 4
- NumberofInputs: 2
- Features: -
- Voltage-Supply: 2V ~ 6V
- Current-Quiescent(Max): 1 µA
- Current-OutputHighLow: 5.2mA, 5.2mA
- LogicLevel-Low: 0.5V ~ 1.8V
- LogicLevel-High: 1.5V ~ 4.2V
- MaxPropagationDelay@VMaxCL: 13ns @ 6V, 50pF
- OperatingTemperature: -55°C ~ 125°C
- MountingType: Surface Mount
- SupplierDevicePackage: 14-TSSOP
- M74HC02TTR STMicroelectronics, IC GATE NOR 4CH 2-INP 14TSSOP, Integrated Circuits (ICs)~Logic - Gates and Inverters
M74HC02TTR, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
