L7808ACF ST IC REG LINEAR 8V 1.5A TO220AB
L7808ACF Images
L7808ACF Images
  • Manufacturer: STMicroelectronics(ST)
  • Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear Package/Case: TO-220-3
  • Description: IC REG LINEAR 8V 1.5A TO220AB
  • COMPETITIVE PRICE and DELIVERY TIME
  • Order with confidence, there are no lead times for in-stock products.
Quickly Quote for You to Meet Your Target Price, Support Small Order Quantity with Fast Quick Delivery.
Download Datasheet (PDF)
L7808ACF Datasheet
ELECTRONIC COMPONENTS, CHOOSE NHE ELECTRONICS
L7808ACF Specifications:
  • MfrPart.: L7808ACF
  • Mfr: STMicroelectronics
  • Description: IC REG LINEAR 8V 1.5A TO220AB
  • Product Category: Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
  • Package: Tube
  • Series: -
  • PartStatus: Obsolete
  • OutputConfiguration: Positive
  • OutputType: Fixed
  • NumberofRegulators: 1
  • Voltage-Input(Max): 35V
  • Voltage-Output(Min/Fixed): 8V
  • Voltage-Output(Max): -
  • VoltageDropout(Max): 2V @ 1A (Typ)
  • Current-Output: 1.5A
  • Current-Quiescent(Iq): 6 mA
  • Current-Supply(Max): -
  • PSRR: 62dB (120Hz)
  • ControlFeatures: -
  • ProtectionFeatures: Over Temperature, Short Circuit
  • OperatingTemperature: 0°C ~ 125°C
  • MountingType: Through Hole
  • Package/Case: TO-220-3
  • L7808ACF STMicroelectronics, IC REG LINEAR 8V 1.5A TO220AB, Integrated Circuits (ICs)~PMIC - Voltage Regulators - Linear
L7808ACF, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
