L6494LD Images
- Manufacturer: STMicroelectronics(ST)
- Category: Integrated Circuits (ICs)~PMIC - Gate Drivers Package/Case: 14-SOIC (0.154, 3.90mm Width)
- Description: IC GATE DRVR HALF-BRIDGE 14SO
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
L6494LD Specifications:
- MfrPart.: L6494LD
- Mfr: STMicroelectronics
- Description: IC GATE DRVR HALF-BRIDGE 14SO
- Product Category: Integrated Circuits (ICs)~PMIC - Gate Drivers
- Package: Tube
- Series: -
- PartStatus: Active
- DrivenConfiguration: Half-Bridge
- ChannelType: Synchronous
- NumberofDrivers: 2
- GateType: IGBT, N-Channel MOSFET
- Voltage-Supply: 10V ~ 20V
- LogicVoltage-VILVIH: 1.45V, 2V
- Current-PeakOutput(SourceSink): 2A, 2.5A
- InputType: CMOS/TTL
- HighSideVoltage-Max(Bootstrap): 500 V
- Rise/FallTime(Typ): 25ns, 25ns
- OperatingTemperature: -40°C ~ 125°C (TJ)
- MountingType: Surface Mount
- Package/Case: 14-SOIC (0.154, 3.90mm Width)
- L6494LD STMicroelectronics, IC GATE DRVR HALF-BRIDGE 14SO, Integrated Circuits (ICs)~PMIC - Gate Drivers
L6494LD, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
