L6389EDTR Images
- Manufacturer: STMicroelectronics(ST)
- Category: Integrated Circuits (ICs)~PMIC - Gate Drivers Package/Case: 8-SOIC (0.154, 3.90mm Width)
- Description: IC GATE DRVR HALF-BRIDGE HI/LO
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
L6389EDTR Specifications:
- MfrPart.: L6389EDTR
- Mfr: STMicroelectronics
- Description: IC GATE DRVR HALF-BRIDGE HI/LO
- Product Category: Integrated Circuits (ICs)~PMIC - Gate Drivers
- Package: Tape & Reel (TR)
- Series: -
- PartStatus: Active
- DrivenConfiguration: Half-Bridge
- ChannelType: Independent
- NumberofDrivers: 2
- GateType: IGBT, N-Channel, P-Channel MOSFET
- Voltage-Supply: 17V (Max)
- LogicVoltage-VILVIH: 1.1V, 1.8V
- Current-PeakOutput(SourceSink): 400mA, 650mA
- InputType: Inverting
- HighSideVoltage-Max(Bootstrap): 600 V
- Rise/FallTime(Typ): 70ns, 40ns
- OperatingTemperature: -45°C ~ 125°C (TJ)
- MountingType: Surface Mount
- Package/Case: 8-SOIC (0.154, 3.90mm Width)
- L6389EDTR STMicroelectronics, IC GATE DRVR HALF-BRIDGE HI/LO, Integrated Circuits (ICs)~PMIC - Gate Drivers
