L6206QTR Images
- Manufacturer: STMicroelectronics(ST)
- Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers Package/Case: 48-VFQFN Exposed Pad
- Description: IC MOTOR DRIVER PAR 48QFN
- COMPETITIVE PRICE and DELIVERY TIME
- Order with confidence, there are no lead times for in-stock products.
Download Datasheet (PDF)
L6206QTR Specifications:
- MfrPart.: L6206QTR
- Mfr: STMicroelectronics
- Description: IC MOTOR DRIVER PAR 48QFN
- Product Category: Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
- Package: Tape & Reel (TR),Cut Tape (CT)
- Series: -
- PartStatus: Active
- OutputConfiguration: Half Bridge (4)
- Applications: DC Motors, Stepper Motors, Voltage Regulators
- Interface: Logic
- LoadType: Inductive
- Technology: BCDMOS
- RdsOn(Typ): 280mOhm LS, 340mOhm HS
- Current-Output/Channel: 2.5A
- Current-PeakOutput: 5.6A
- Voltage-Supply: 8V ~ 52V
- Voltage-Load: 8V ~ 52V
- OperatingTemperature: -25°C ~ 125°C (TJ)
- Features: Bootstrap Circuit
- FaultProtection: Current Limiting, Over Temperature, UVLO
- MountingType: Surface Mount
- Package/Case: 48-VFQFN Exposed Pad
- L6206QTR STMicroelectronics, IC MOTOR DRIVER PAR 48QFN, Integrated Circuits (ICs)~PMIC - Full, Half-Bridge Drivers
L6206QTR, ST authentic parts in stock from STMicroelectronics authorized distributors, order today, can ship immediately.
